Kenwood eXcelon DMX1058XR 10.1" HD Wireless CarPlay/Android Auto Digital Multimedia Receiver

Kenwood eXcelon DMX1058XR is a 10.1" HD floating-screen digital multimedia receiver designed for wireless smartphone integration, multi-camera expansion, and advanced system control. This model is a digital multimedia receiver (does not play discs).

Key Features

• 10.1" HD (1280 x 720) capacitive touchscreen display
• Floating panel mechanism with 4-way position adjustment (depth/height/tilt/left-right)
• Wired and wireless Apple CarPlay support
• Android Auto support (wired and wireless)
• Built-in Wi-Fi for wireless smartphone connectivity
• Built-in Bluetooth (Ver 5.2) for hands-free calling and audio streaming
• Built-in HD Radio tuner
• SiriusXM Ready and SiriusXM 360L Ready (optional tuner required)
• 4 camera inputs; HD front/rear camera ready
• 3 preouts (5V) and digital optical output

Connectivity & Integration

• Wired and wireless Apple CarPlay
• Android Auto (wired and wireless)
• Bluetooth audio streaming and hands-free calling (Bluetooth 5.2)
• High-Resolution Audio Wireless via LDAC (compatible devices required)
• USB Type-C connection (USB 2.0 High Speed), with included USB Type-C cable and USB Type-A adapter; up to 3.0A charging
• Wireless Mirroring for Smartphone (selected smartphones only)
• HDMI mirroring support (optional KCA-HD200 HDMI cable required)
• 4 camera inputs, including support for Kenwood DRV-N520 drive recorder (sold separately)
• HD front/rear camera ready (Kenwood CMOS-740HD camera sold separately)
• SiriusXM-ready with add-on tuner: SXV300V1 SiriusXM Tuner
• Add a Kenwood camera: CMOS-740HDLP, CMOS-320LP, CMOS-240U, CMOS-230LP

Audio & System Control

• 13-band graphic equalizer
• Digital time alignment
• Parametric equalizer (multi-point tuning)
• 3 preamp outputs (5V)
• Digital optical output for DSP integration
• Internal amplifier: 50W x 4 max; 29W x 4 typical (4Ω, 1kHz, 10% THD)

Installation & Fitment Notes

• Floating-screen chassis with adjustable monitor positioning for vehicle fitment
• iDatalink Maestro RR/RR2 compatible for factory feature retention and vehicle info display (module/adapter required)
• Parking brake connection required to access certain settings and video functions
• Vehicle-specific dash kit and wiring interface required (sold separately)

Technical Specifications

• Brand: Kenwood eXcelon
• Model: DMX1058XR
• Screen Size: 10.1" HD capacitive touchscreen
• Resolution: 1280 x 720
• Smartphone Integration: Wired/wireless CarPlay; wired/wireless Android Auto
• Wi-Fi: IEEE 802.11 a/b/g/n/ac
• Bluetooth: Ver 5.2
• USB: USB Type-C (USB2.0 High Speed), up to 3.0A charging
• Camera Inputs: 4
• HD Camera Ready: Yes (front/rear)
• Preamp Outputs: 3 (5V)
• Digital Output: Optical
• Disc Support: None (digital multimedia receiver)
• Chassis Type: Floating-screen (monitor with receiver)

Identifiers & Packaging

• Manufacturer Part Number (MPN): DMX1058XR
• UPC: 019048240842
• Sold As: Each
• Included Components: Receiver/monitor, floating mount hardware, wiring harness, USB Type-C cable, USB Type-A adapter, documentation

Why Buy From MCOR Automotive

• Kenwood Preferred Retailer (online and in-store)
• Specialists in vehicle-specific audio integration
• Expert support for system selection and clean installation guidance

Vehicle Fitment & Installation Notes

• Most vehicles require additional installation parts when replacing the factory radio. Depending on the vehicle, you may need a dash kit, wiring harness, antenna adapter, steering wheel control interface, factory amplifier integration module, or other vehicle-specific parts.
• Vehicle-specific installation parts are sold separately unless included in the bundle.
• Use the MCOR Automotive Vehicle Fit Guide to help identify required parts for your vehicle, or contact MCOR Automotive through the chat button for help building the correct vehicle-specific install package.
• Do not assume universal fitment. Radio fitment and retained factory features depend on the vehicle, trim, factory audio system, and required installation interfaces.
