Fusion XS Series Marine Subwoofers, 10" 600-Watt Peak Classic Marine Subwoofer — 010-02198-00
Fusion XS Series Marine Subwoofers, 10" 600-Watt Peak Classic Marine Subwoofer — 010-02198-00
Regular price
$199.99 USD
Regular price
Sale price
$199.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Before you order
Buy with the right details confirmed
✓
Review the application and system requirements
Confirm the size, power, connections, and included or separately required parts described on this page.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Fusion XS Series Marine Subwoofers, 10" 600-Watt Peak Classic Marine Subwoofer — Tailor the look of your boat with the included interchangeable grille colors, while adding a 10-inch XS Series subwoofer for dedicated bass. Match the continuous power rating and mounting dimensions below to your system.
Why choose this model
- Interchangeable grille colors included in the selected classic or sports style
- IP65 marine protection
- 4-ohm nominal impedance
- Three-year manufacturer warranty
Specifications and product identity
| Manufacturer part number | 010-02198-00 |
|---|---|
| UPC | 753759221508 |
| Item condition | New |
| Warranty | 3 years |
| Water And Dust Rating | IP65 |
| Continuous Power Handling (Rms) | 120 W |
| Sensitivity (Spl @ 1 W/1 M) | 87 dB |
| Frequency Response (+/- 3 Db) | 30 Hz-2 kHz |
| Nominal Impedance | 4 Ω |
| Mounting Diameter Clearance | 8.78" (223 mm) |
| Mounting Depth Clearance | 4.45" (113 mm) |
Compatibility and installation planning
- Match amplifier output, impedance and crossover settings to the continuous (RMS) rating. Peak power is not the continuous amplifier-sizing target.
- A nominal speaker size does not guarantee drop-in fit. Check the cutout, mounting depth and clearance behind the installation surface.
- This is a passive subwoofer, not a powered bass system. An appropriate external amplifier is required.
What’s included
- One subwoofer
- Manufacturer documentation
- Classic white and black grilles
- Mounting screws
Related products and system add-ons
Sold separately. Check the compatibility notes above and each linked product before adding accessories.
- Fusion Marine Speaker Cables, 12 AWG (3.3 sq mm), 25 ft (7.62 m) Cable
- Fusion MS-RA210 2-zone DSP marine stereo
- Explore the Fusion marine audio collection
Build the right system with MCOR
Need help matching the receiver, speakers, amplifier or installation accessories? Contact MCOR with your existing equipment model numbers and installation details before ordering.
