Kenwood eXcelon XR901-5 900-Watt 5-Channel Class D Car Amplifier

The Kenwood eXcelon XR901-5 is a compact 5-channel Class D amplifier built for buyers who want to power a full speaker system and subwoofer from one chassis without giving up installation flexibility. Its low-profile eXcelon design fits tighter vehicle spaces while still delivering clean full-range output for front and rear speakers plus dedicated mono subwoofer power.

This amplifier is rated at 60 watts RMS x 4 + 400 watts RMS x 1 at 4 ohms, 75 watts RMS x 4 + 600 watts RMS x 1 at 2 ohms, and 150 watts RMS x 2 bridged + 400 watts RMS x 1 at 4 ohms. That makes it a strong fit for buyers who want one amp to handle door speakers and a subwoofer in a clean, space-saving system design.

Key Features

• 900-watt 5-channel Class D amplifier
• 60 watts RMS x 4 + 400 watts RMS x 1 at 4 ohms
• 75 watts RMS x 4 + 600 watts RMS x 1 at 2 ohms
• 150 watts RMS x 2 bridged + 400 watts RMS x 1 at 4 ohms
• Compact eXcelon chassis
• Variable high-pass and low-pass filters
• Variable bass boost on subwoofer channel
• Speaker-level inputs
• Signal-sensing turn-on
• Cooling fan
• Wired remote bass controller included
• 2-year warranty

Connectivity & Integration

• Amplifier type: 5-channel Class D full-range/subwoofer amplifier
• Speaker-level input: Yes, for easier integration with compatible factory or aftermarket source units
• Signal-sensing turn-on: Yes
• Remote level control: Wired remote bass controller included
• Application: Designed to power front and rear speakers plus a dedicated subwoofer channel from one amplifier

Power & System Control

• CTA-2006-D rated output of 70W x 4 + 500W x 1 at 4 ohms maximum dynamic power
• Continuous power output of 60W x 4 + 400W x 1 at 4 ohms
• 75W x 4 + 600W x 1 at 2 ohms
• 150W x 2 bridged + 400W x 1 at 4 ohms
• Front and rear channels include variable high-pass and low-pass filters
• Subwoofer channel includes variable low-pass filter and bass boost
• Cooling fan helps manage heat in higher-output installs

Installation & Fitment Notes

• Amplifier type: 5-channel full-range/subwoofer amplifier
• Chassis size: Compact footprint for easier mounting in tighter spaces
• Dimensions: 10-1/4" W x 2" H x 6-5/8" D
• Operating voltage: 14.4V nominal, 11V-16V allowable
• Current consumption: 80A
• Proper power wire, ground, fuse protection, and speaker load configuration should be confirmed before installation
• This amplifier is designed for full-system use with four speaker channels plus one subwoofer channel

Technical Specifications

• Model: XR901-5
• Amplifier class: Class D
• Channels: 5
• RMS power at 4 ohms: 60W x 4 + 400W x 1
• RMS power at 2 ohms: 75W x 4 + 600W x 1
• Bridged power at 4 ohms: 150W x 2 + 400W x 1
• Maximum power: 1800W
• Frequency response: 20Hz-20kHz (±1dB)
• Input sensitivity: 0.2V-5.0V
• Signal-to-noise ratio: 79dBA x 4 / 78dBA x 1
• Dimensions: 260 x 51 x 169mm
• Weight: 2.4kg

Identifiers & Packaging

• Manufacturer Part Number (MPN): XR901-5
• UPC: 019048222435
• Sold As: Each
• Included Components: XR901-5 amplifier, wired remote bass controller, and manufacturer-supplied accessories/documentation
