Sony XM-8ES 8-Channel Class-D 100W x 8 RMS @ 4Ω Full-Range Amplifier

Sony XM-8ES is an 8-channel Class-D amplifier designed for full-range speaker systems that need high continuous output, flexible channel configuration, and compact installation. It supports multi-channel and bridged layouts for active front stages, full-vehicle speaker systems, or expanded multi-zone car audio installations.

Key Performance Features

• Class-D 8-channel amplifier design
• 100W x 8 RMS at 4 ohms
• 165W x 8 RMS at 2 ohms
• 330W x 4 RMS bridged at 4 ohms
• CTA-2006 compliant power rating
• High-Resolution Audio compatible
• Resonance-damping aluminum chassis construction
• Gold-plated connectors and speaker terminals

System Configuration & Flexibility

• 8-channel full-range amplifier
• Supports 8ch / 7ch / 6ch / 5ch / 4ch / 3ch / 2ch channel configuration layouts
• Four pairs of channels can be bridged for higher-power speaker operation
• RCA line-level input for aftermarket source units and processors
• Speaker-level input for factory audio integration
• Suitable for active and passive multi-speaker system designs

Power Output

• RMS @ 4Ω: 100W x 8
• RMS @ 2Ω: 165W x 8
• Bridged RMS @ 4Ω: 330W x 4
• CTA-2006 Power Output: 100W x 8

Signal Control & Protection

• Variable high-pass filter: 500 Hz - 5 kHz
• Variable low-pass filter: 50 Hz - 500 Hz
• High-pass filter slope: 12 dB/oct
• Low-pass filter slope: 12 dB/oct
• Protection circuitry for thermal and electrical operating conditions

Installation Notes

• Compact chassis supports under-seat or multi-amp rack installation depending on vehicle and layout
• Proper power wire, ground wire, fuse protection, and signal wiring are required and sold separately unless otherwise noted
• Suitable for full-range speaker systems using 2-ohm, 4-ohm, or bridged 4-ohm channel configurations within rated specifications

Technical Specifications

• Brand: Sony
• Model: XM-8ES
• Amplifier Class: Class-D
• Channels: 8
• Channel Configuration: 8ch / 7ch / 6ch / 5ch / 4ch / 3ch / 2ch
• RMS Power @ 4Ω: 100W x 8
• RMS Power @ 2Ω: 165W x 8
• Bridged RMS @ 4Ω: 330W x 4
• CTA-2006 Power Output: 100W x 8 at 1 kHz, 1% THD
• Frequency Response: 10 Hz - 40 kHz
• Signal-to-Noise Ratio: 100 dB
• Total Harmonic Distortion at 1 kHz: Less than 0.05%
• High-Pass Filter: Variable 500 Hz - 5 kHz
• Low-Pass Filter: Variable 50 Hz - 500 Hz
• Speaker Level Input: Yes
• Dimensions (W x H x D): 14.96" x 2.36" x 8.46"
• Weight: 9.19 lb

Identifiers & Packaging

• Manufacturer Part Number (MPN): XM-8ES
• UPC: 027242925670
• Sold As: Each
• Included Components: Amplifier, mounting hardware, hex wrench, and documentation

Compatibility / Installation Notes

• Amplifiers require proper power wire, ground, fuse protection, speaker wiring, signal integration, and gain / crossover setup.
• Confirm speaker or subwoofer impedance and RMS power handling before pairing this amplifier with a system.
• Professional installation is recommended for safe wiring, correct tuning, and long-term reliability.
