Sony XM-6ES 6-Channel Class-D 100W x 6 RMS @ 4Ω Full-Range Amplifier

Sony XM-6ES is a 6-channel Class-D amplifier designed for full-range speaker systems that need high continuous output, flexible channel configuration, and compact installation. It supports 6-channel, 5-channel, 4-channel, 3-channel, and bridged system layouts with RCA and speaker-level input capability for aftermarket or factory-integrated audio systems.

Key Performance Features

• Class-D 6-channel amplifier design
• 100W x 6 RMS at 4 ohms
• 165W x 6 RMS at 2 ohms
• 330W x 3 RMS bridged at 4 ohms
• CTA-2006 compliant power rating
• High-Resolution Audio compatible signal path
• Resonance-damping aluminum chassis construction
• Gold-plated terminals and signal connections

System Configuration & Flexibility

• 6-channel full-range amplifier
• Supports 6-channel, 5-channel, 4-channel, 3-channel, and 2-channel system layouts
• Three pairs of channels can be bridged for higher-power speaker operation
• RCA line-level input for aftermarket source units and processors
• Speaker-level input for factory audio integration
• Signal summing supports installation with factory stereo outputs
• Line-level pass-through supports expanded multi-amp systems

Power Output

• RMS @ 4Ω: 100W x 6
• RMS @ 2Ω: 165W x 6
• Bridged RMS @ 4Ω: 330W x 3
• CTA-2006 Power Output: 100W x 6

Signal Control & Protection

• Variable high-pass filter: 500 Hz - 5 kHz
• Variable low-pass filter: 50 Hz - 500 Hz
• High-pass filter slope: 12 dB/oct
• Low-pass filter slope: 12 dB/oct
• Protection circuitry for thermal and electrical operating conditions

Installation Notes

• Compact chassis supports flexible amplifier mounting locations
• Proper power wire, ground wire, fuse protection, and signal wiring are required and sold separately unless otherwise noted
• Suitable for full-range speaker systems using 2-ohm, 4-ohm, or bridged 4-ohm channel configurations within rated specifications

Technical Specifications

• Brand: Sony
• Model: XM-6ES
• Amplifier Class: Class-D
• Channels: 6
• Channel Configuration: 6ch / 5ch / 4ch / 3ch / 2ch
• RMS Power @ 4Ω: 100W x 6
• RMS Power @ 2Ω: 165W x 6
• Bridged RMS @ 4Ω: 330W x 3
• CTA-2006 Power Output: 100W x 6 at 4 ohms, 1% THD
• Frequency Response: 10 Hz - 40,000 Hz
• Total Harmonic Distortion at 1 kHz: Less than 0.05%
• Signal-to-Noise Ratio: 100 dB
• High-Pass Filter: Variable 500 Hz - 5,000 Hz
• Low-Pass Filter: Variable 50 Hz - 500 Hz
• Speaker Level Input: Yes
• Dimensions (W x H x D): 14.96" x 2.36" x 8.46"
• Weight: 8.95 lb / 4.06 kg

Identifiers & Packaging

• Manufacturer Part Number (MPN): XM-6ES
• UPC: 027242925663
• Sold As: Each
• Included Components: Amplifier, four 30-amp ATO fuses, mounting hardware, hex wrench, and documentation

Compatibility / Installation Notes

• Amplifiers require proper power wire, ground, fuse protection, speaker wiring, signal integration, and gain / crossover setup.
• Confirm speaker or subwoofer impedance and RMS power handling before pairing this amplifier with a system.
• Professional installation is recommended for safe wiring, correct tuning, and long-term reliability.
