Race Sport Lighting RS72 ECO-Light 72W Straight Combination-Beam LED Bar
Race Sport Lighting RS72 ECO-Light 72W Straight Combination-Beam LED Bar
Couldn't load pickup availability
Buy with the right details confirmed
Confirm the size, power, connections, and included or separately required parts described on this page.
Professional installation is recommended for this product.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Add a compact combination-beam light bar for a planned off-road or work-light installation. The straight housing uses 3D reflector optics to combine near-area and distance-oriented illumination.
At a Glance
- Straight light-bar design
- Combination beam
- 3D reflector optics
- Measured mounting footprint provided
Compatibility & Installation Requirements
Allow space for the full 17-inch mounted span. The dealer nominal title says 12.5 inches while the dimensional body says 14 inches; confirm the actual bracket and lamp before drilling.
Use a fused power circuit and correctly rated wiring, switching and relays. Protect connections from water and abrasion, and verify mounting clearance through the full range of vehicle movement. Professional installation is recommended.
Included Equipment
- One RS72 ECO-Light LED light bar
Technical Specifications
| Brand | Race Sport Lighting |
|---|---|
| Model | RS72 |
| UPC | 814843021807 |
| Sold as | One product or kit as described |
| Power rating | 72 W |
| Supply voltage | 9–16 V DC |
| Stated current | 5.7 A |
| Manufacturer output | 4680 lm |
| Published body length | 14 inches |
| Length including mount | 17 inches |
| Body height | 3 inches |
| Mounted height | 4 inches |
Manufacturer Resources & Warranty
One-year manufacturer warranty, subject to terms.
Help Choosing Your Setup
Tell MCOR Automotive your vehicle or vessel, intended mounting location and lighting goal. Contact us for help checking the lighting size, power requirements and installation parts before ordering.
