Race Sport Lighting MSMH12BSW White LED Marine Masthead Light, Black Housing
Race Sport Lighting MSMH12BSW White LED Marine Masthead Light, Black Housing
Couldn't load pickup availability
Buy with the right details confirmed
Confirm the size, power, connections, and included or separately required parts described on this page.
Professional installation is recommended for this product.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Provide a compact white masthead-light fixture for a properly specified vessel installation. The black ABS housing uses a 12–24-volt DC supply.
At a Glance
- White LED light
- Black ABS shell
- Compact screw-mounted fixture
- IP67 environmental rating
Compatibility & Installation Requirements
Verify required visibility range, mounting height, arc and approval for the vessel. Although the dealer title also mentions stern use, its 225-degree masthead specification is not a 135-degree stern-light specification.
Confirm the vessel mounting surface, power supply, wire routing and required sealing method. Use marine-rated circuit protection and secure watertight connections. Accent or work lighting does not replace the vessel navigation lights required for its size and use.
Included Equipment
- MSMH12BSW white LED light
Technical Specifications
| Brand | Race Sport Lighting |
|---|---|
| Model | MSMH12BSW |
| UPC | 810077230510 |
| Sold as | One product or kit as described |
| Supply voltage | 12–24 V DC |
| Power rating | 1.2 W |
| Housing dimensions | 76 x 62 x 57 mm |
| Published masthead arc | 225° |
| Color | White |
| Environmental rating | IP67 |
Manufacturer Resources & Warranty
One-year manufacturer warranty, subject to terms.
Help Choosing Your Setup
Tell MCOR Automotive your vehicle or vessel, intended mounting location and lighting goal. Contact us for help checking the lighting size, power requirements and installation parts before ordering.
