Race Sport Lighting MS120WWDS 22.25-Inch Marine Dual-Row White LED Light Bar
Race Sport Lighting MS120WWDS 22.25-Inch Marine Dual-Row White LED Light Bar
Couldn't load pickup availability
Buy with the right details confirmed
Confirm the size, power, connections, and included or separately required parts described on this page.
Professional installation is recommended for this product.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Add white-housing marine work lighting with a straight dual-row bar. The aluminum construction and forty three-watt LEDs suit a properly mounted deck, docking or work-light installation.
At a Glance
- Straight white-housing construction
- Forty 3 W LEDs
- Polycarbonate lens
- IP67 environmental rating
Compatibility & Installation Requirements
Measure the mounting span, available depth and beam position. Verify power requirements with the supplied instructions; source voltage tables conflict, so no expanded voltage range is promised.
Confirm the vessel mounting surface, power supply, wire routing and required sealing method. Use marine-rated circuit protection and secure watertight connections. Accent or work lighting does not replace the vessel navigation lights required for its size and use. The MSLBWAH harness and switch are separate; alternatively use a correctly designed hardwire circuit.
Included Equipment
- MS120WWDS light bar and mounting brackets
Technical Specifications
| Brand | Race Sport Lighting |
|---|---|
| Model | MS120WWDS |
| UPC | 817999028638 |
| Sold as | One product or kit as described |
| End-to-end length | 22.25 inches |
| Lens width | 20 inches |
| Mounting-hole spacing | 23.5 inches |
| Height x depth | 3 x 3.5 inches |
| Power rating | 120 W |
| Manufacturer output | 8400 lm |
| Color temperature | 6000 K |
Manufacturer Resources & Warranty
Limited lifetime manufacturer warranty, subject to terms.
Help Choosing Your Setup
Tell MCOR Automotive your vehicle or vessel, intended mounting location and lighting goal. Contact us for help checking the lighting size, power requirements and installation parts before ordering.
