Kicker SoloXS 52L7XS122 12" Square Competition Subwoofer, 3000W RMS, 2Ω DVC

Kicker SoloXS 52L7XS122 12" Square Competition Subwoofer, 3000W RMS, 2Ω DVC

A high-excursion square subwoofer for demanding custom bass systems. The 12-inch SoloXS combines substantial power handling with a serviceable cone assembly, making enclosure and amplifier planning essential.

Key Features

• Forced-Air Cooling and cast-aluminum basket
• Dual-spider suspension with reinforced tinsel leads
• Field-replaceable, bolt-in recone assembly available separately

Technical Specifications

• Size: 12 inches
• Voice coils: dual 2Ω
• Recommended amplifier power: 1500–3000W RMS
• Frequency response: 20–100 Hz
• Recommended vented box: 3.0 cu. ft. net volume, port volume excluded
• Mounting depth: 10-1/8 inches
• Square mounting cutout: 11-1/16 inches

Application & Installation

• One driver presents 1Ω parallel or 4Ω series; both coils must be wired correctly.
• Choose an amplifier stable at the final load and size the electrical system for its current demand.
• Requires a suitable square-cutout enclosure and external amplifier; neither is included.
• Use the manufacturer enclosure drawings for port dimensions, displacement and installation clearance.

Identifiers & Packaging

• Brand: Kicker
• MPN: 52L7XS122
• UPC: 713034092162
• Sold as: One complete subwoofer driver

Manufacturer installation manual

MCOR Automotive is an authorized Kicker retailer. Contact us for amplifier, enclosure, or installation-part matching before you order.
