Product Overview

The Kenwood KFC-XW1241's X-Motif Cone optimizes resonance, eliminating unwanted frequencies for robust, clear bass. Its efficient thermal management, featuring an Aluminum Bobbin, Closed Yoke, and Advanced Airflow Control, ensures longevity. The Stress Controlled Spider, with a computer-optimized damper, enhances durability. This subwoofer is expertly power-matched with the eXcelon X502-1 amplifier.

Features

• Diamond Array Pattern with X-Motif Cone
• Advanced Airflow Control with Closed Yoke

• Stress Controlled Spider

• Ideal Pairing: eXcelon X502-1 Amplifier

Model	Type	Inner Volume	W	H	D	Mounting Hole	SW	SH	SL
KFC-XW1241	Sealed	1.25 cft (35.4 liter)	18" (457mm)	14-1/4" (362mm)	11-3/4" (299mm)	11-1/8" (282mm)
	Ported	1.50 cft (42.5 liter)	20" (508mm)	14-1/4" (362mm)	15-1/2" (394mm)		1-3/8" (35mm)	12-3/4" (324mm)	29" (736mm)



General Features

ELECTRICAL
Impedance (Ω)	4
Peak Input Power (W)	2000
RMS Power (W)	300
Sensitivity (dB at 1m)	85
Frequency Response (Hz)	29 ~ 300
MOUNTED SPEAKER
Size	300mm	12 inch
Diaphragm	Paper
Cap	Injection PP
Surround	Urethane
Basket	Steel
Gasket	ABS
Magnet	Ferrite	φ134-φ70-t30
DIMENSION
Width	326mm	12 - 13/16 inch
Height	326mm	12 - 13/16 inch
Cut-out Diameter	279mm	11 inch
Depth	155.4mm	6 - 1/8 inch
Mounting Depth	137mm	5 - 3/8 inch
WEIGHT
Woofer without Gasket	4.2 kg	9.3 lb
Gross Weight	5.0 kg	11.0 lb
Weight of Magnet	1560 g	54.9 oz
ACCESSORY	Instruction Manual
	Warranty Card
SPECIAL FEATURE	Injection PP X-motif Cone with
	Diamond Array Pattern
	Closed Yoke with Advanced
	Airflow Control
	Aluminum Bobbin
