Fusion Signature Series Monoblock Marine Subwoofer Amplifier — 010-01970-00
Fusion Signature Series Monoblock Marine Subwoofer Amplifier — 010-01970-00
Regular price
$449.99 USD
Regular price
Sale price
$449.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Before you order
Buy with the right details confirmed
✓
Review the application and system requirements
Confirm the size, power, connections, and included or separately required parts described on this page.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Fusion Signature Series Monoblock Marine Subwoofer Amplifier — Power a dedicated marine subwoofer with a Class-D monoblock amplifier offering adjustable filtering and substantial continuous output, without confusing the peak rating with RMS power.
Why choose this model
- Class-D design with a rigid aluminum heat sink
- Conformal-coated circuit boards for marine-environment protection
- Adjustable subsonic and low-pass filtering
- Designed for subwoofer duty, not full-range speakers
Specifications and product identity
| Manufacturer part number | 010-01970-00 |
|---|---|
| UPC | 753759153007 |
| Item condition | New |
| Continuous power at 14.4 V, less than 1% THD | 500 W x 1 at 4 ohms; 850 W x 1 at 2 ohms |
| Operating voltage | 10.8–16 VDC |
| Dimensions | 300 x 210 x 50 mm |
| Maximum current consumption | 120 A |
| Manufacturer warranty | 3 years |
Compatibility and installation planning
- This is a 12-volt-system amplifier, not the 24-volt Signature model.
- Select marine-rated power/ground cable and battery-side protection from the exact installation manual for your cable length and load. An amplifier wiring kit is not included.
- Match subwoofer impedance, continuous power handling and crossover settings before installation.
What’s included
- Signature Series monoblock amplifier
- Four mounting screws
- 3 mm and 2.5 mm hex keys
- Polishing cloth
- Spare J1171-compliant 40 A blade-type fuses
Related products and system add-ons
Sold separately. Check the compatibility notes above and each linked product before adding accessories.
- Fusion Performance RCA Cables, 2 Channel, 6 ft Cable
- Fusion Marine Speaker Cables, 12 AWG (3.3 sq mm), 25 ft (7.62 m) Cable
- Explore the Fusion marine audio collection
Build the right system with MCOR
Need help matching the receiver, speakers, amplifier or installation accessories? Contact MCOR with your existing equipment model numbers and installation details before ordering.
