Fusion MS-RA60 2-zone Bluetooth marine stereo — 010-02405-00
Fusion MS-RA60 2-zone Bluetooth marine stereo — 010-02405-00
Regular price
$249.99 USD
Regular price
Sale price
$249.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Before you order
Buy with the right details confirmed
✓
Review the application and system requirements
Confirm the size, power, connections, and included or separately required parts described on this page.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Fusion MS-RA60 2-zone Bluetooth marine stereo — Choose straightforward helm audio with the compact RA60: Bluetooth streaming, familiar radio controls and separate volume control for two listening areas.
Why choose this model
- 2.3-inch monochrome LCD
- Two zones and four amplified speaker channels
- Bluetooth, AM/FM and AUX sources
- 22 W RMS x 4 at 14.4 V, 4 ohms, less than 10% THD
- IPX6/IPX7 front panel when properly installed
- Does not provide the Fusion DSP platform required by Apollo amplifiers
Specifications and product identity
| Manufacturer part number | 010-02405-00 |
|---|---|
| UPC | 753759250300 |
| Item condition | New |
| Dimension | 6.18" x 2.68" x 4.06" (156 x 68 x 103.2 mm) |
| Water Rating | IPX6 and IPX7 (front panel only, when properly installed) |
| Display | 2.3" perimeter bonded monochrome LCD |
| Current (Max) | 15 A |
| Power Input | 10.8 - 16 VDC |
| Rated Power Output (4 Ohm) | 22 watts RMS x 4 @ 14.4 V input < 10% THD |
| Auxiliary Inputs (Rca) | 1 |
| Speaker Connections | 4 (2 zone amplified) |
| Rca Pre-Out (Left, Right And Subwoofer) | 1 zone (requires external amplification) |
| Line Out | Zone 1 (L + R, requires external amplification) |
| Subwoofer Out | Zone 1 (mono output, requires external amplification) |
Compatibility and installation planning
- Confirm mounting cutout, rear clearance, system voltage and network requirements before ordering. Water ratings depend on correct installation.
- Speakers, external amplifiers, antennas and optional network equipment are separate unless explicitly listed below.
What’s included
- Fusion MS-RA60 marine stereo
- Mounting gasket
- Four 6-gauge, self-tapping screws
- Two screw covers
- Power and speaker wiring harness
- Auxiliary-in, line-out, and subwoofer-out wiring harnesses
- Documentation
