Fusion Apollo MS-RA670 3-zone DSP marine stereo — 010-02138-00
Fusion Apollo MS-RA670 3-zone DSP marine stereo — 010-02138-00
Regular price
$549.99 USD
Regular price
Sale price
$549.99 USD
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Before you order
Buy with the right details confirmed
✓
Review the application and system requirements
Confirm the size, power, connections, and included or separately required parts described on this page.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Fusion Apollo MS-RA670 3-zone DSP marine stereo — Build a multi-zone Fusion system without needing the larger touchscreen chassis: the RA670 combines wired networking, DSP and three-zone control.
Why choose this model
- Three independently controlled audio zones
- Fusion DSP setup through the Garmin Audio app
- Wired Ethernet networking; no built-in Wi-Fi
- Bluetooth, USB, AUX and optical audio inputs
- NMEA 2000 and ERX/NRX remote support
- SiriusXM-ready; compatible tuner and subscription sold separately
Specifications and product identity
| Manufacturer part number | 010-02138-00 |
|---|---|
| UPC | 753759221751 |
| Item condition | New |
| Water Rating | IPX6 and IPX7 (front panel only, when properly installed) |
| Current (Max) | 15 A |
| Power Input | 10.8 - 16 VDC |
| Rated Power Output (4 Ohm) | 26 watts RMS x 4 @ 14.4 V input < 10% THD |
| Auxiliary Inputs (Rca) | 1 |
| Ethernet Ports | 1 |
| Usb 2.0 Ports | 1 |
| Speaker Connections | 4 (2 zone amplified) |
| Rca Pre-Out (Left, Right And Subwoofer) | 3 zones (requires external amplification) |
| Line Out | 3 (L + R per zone, requires external amplification) |
| Subwoofer Out | 3 (1 mono output per zone, requires external amplification) |
Compatibility and installation planning
- Confirm mounting cutout, rear clearance, system voltage and network requirements before ordering. Water ratings depend on correct installation.
- Speakers, external amplifiers, antennas and optional network equipment are separate unless explicitly listed below.
- AirPlay/network streaming requires an appropriately configured compatible network; this model does not include built-in Wi-Fi.
What’s included
- Fusion MS-RA670 marine stereo
- Mounting gasket
- Four 8-gauge, self-tapping screws
- Two screw covers
- Power and speaker wiring harness
- Auxiliary-in, line-out, and subwoofer-out wiring harnesses
- Dust cover
- 6 ft (2 meter) NMEA 2000 drop cable
- Documentation
Related products and system add-ons
Sold separately. Check the compatibility notes above and each linked product before adding accessories.
- Fusion XS Series Marine Speakers, 6.5" 200-Watt Peak Classic Marine Speakers (Pair)
- Fusion Marine Speaker Cables, 16 AWG (1.3 sq mm), 25 ft (7.62 m) Cable
- Fusion Stealth Antenna
- Fusion Apollo MS-ERX400 Wired Remote with Ethernet Connectivity
- Fusion Apollo 4-Channel Marine Amplifier
- Explore the Fusion marine audio collection
Build the right system with MCOR
Need help matching the receiver, speakers, amplifier or installation accessories? Contact MCOR with your existing equipment model numbers and installation details before ordering.
