AudioControl LC1i 2-Channel Line Output Converter & Line Driver
AudioControl LC1i 2-Channel Line Output Converter & Line Driver
Couldn't load pickup availability
Buy with the right details confirmed
Confirm the size, power, connections, and included or separately required parts described on this page.
Professional installation is recommended for this product.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Convert a compatible factory speaker-level signal to RCA or strengthen an existing line-level signal with the AudioControl LC1i. Selectable loading and three turn-on options make it useful for an amplifier addition without claiming vehicle-specific plug-and-play compatibility.
At a Glance
- Two speaker-level and two line-level input channels
- Two RCA output channels
- Selectable 20-ohm / 60-ohm / 20-kOhm speaker-input load
- Remote, GTO or audio-sensing turn-on
- Ground-isolation selection
Compatibility & Installation Requirements
Use with a compatible factory or aftermarket audio signal and downstream amplifier. Verify input voltage, channel routing and grounding for the actual system. This active unit requires appropriate fused power and ground wiring; it is not a vehicle-specific plug-and-play harness. LC1i is not advertised as having AccuBASS bass-restoration/roll-off correction; choose the correct processor if that function is required.
Included Equipment
- LC1i
- Speaker/power connectors
- Manufacturer documentation
Technical Specifications
| Brand | AudioControl |
|---|---|
| Model | LC1i |
| UPC | 851523007799 |
| Sold as | Each (one product) |
| Maximum speaker input | 40 Vrms / 400 W at the 20 kOhm setting |
| Line-input impedance | 7 kOhms |
| Maximum output | 9.5 Vrms / 13 V peak |
| Current draw / recommended fuse | 120 mA / 1 A |
| Dimensions, L x D x H | 4.8 x 3 x 1 inches including connectors |
Manufacturer Resources & Warranty
One-year manufacturer warranty, subject to AudioControl eligibility and installation terms. Extended professional-installation coverage is not automatically included with a shipped product. View manufacturer warranty terms.
Help Choosing Your Setup
Tell MCOR Automotive your vehicle, factory or aftermarket radio, speakers and planned amplifier configuration. Contact us for help checking the signal path and installation requirements before you order.
