AudioControl ACX-300.1 IPX6 Monoblock Amplifier with AccuBASS
AudioControl ACX-300.1 IPX6 Monoblock Amplifier with AccuBASS
Couldn't load pickup availability
Buy with the right details confirmed
Confirm the size, power, connections, and included or separately required parts described on this page.
Professional installation is recommended for this product.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
Add a dedicated subwoofer channel to a compatible marine, motorcycle or powersports system with the ACX-300.1. It combines IPX6 protection, selectable input modes and AccuBASS adjustment in an amplifier rated for 175 watts RMS at 4 ohms or 300 watts RMS at 2 ohms.
At a Glance
- 175 W RMS at 4 ohms or 300 W RMS at 2 ohms
- IPX6 rating
- AccuBASS adjustment
- GTO signal-sensing turn-on
- Selectable 80 Hz, 120 Hz or bypass crossover
Compatibility & Installation Requirements
Universal amplifier installation requires a compatible audio signal, suitable speakers, correctly sized fused power and ground wiring, and a secure ventilated mounting location. Wiring and vehicle-specific integration parts are selected separately. Match speaker impedance and output power before installation; this is not a vehicle-specific plug-and-play kit. IPX6 does not mean the amplifier or its connections may be submerged.
Included Equipment
- ACX-300.1 amplifier
- Manufacturer documentation
Technical Specifications
| Brand | AudioControl |
|---|---|
| Model | ACX-300.1 |
| UPC | 851523007829 |
| Sold as | Each (one product) |
| RMS power at 14.4 V | 175 W x 1 at 4 ohms; 300 W x 1 at 2 ohms |
| Low-level input range | 0.5–6 Vrms |
| High-level input range | 1–12 Vrms |
| Crossover | 12 dB/octave Linkwitz-Riley, 80 Hz / 120 Hz / bypass |
| Recommended fuse | 30 A |
| Ingress rating | IPX6 |
Manufacturer Resources & Warranty
One-year manufacturer warranty, subject to AudioControl eligibility and installation terms. Extended professional-installation coverage is not automatically included with a shipped product. View manufacturer warranty terms.
Help Choosing Your Setup
Tell MCOR Automotive your vehicle, factory or aftermarket radio, speakers and planned amplifier configuration. Contact us for help checking the signal path and installation requirements before you order.
