AudioControl A800.1 Altitude Monoblock Subwoofer Amplifier
AudioControl A800.1 Altitude Monoblock Subwoofer Amplifier
Couldn't load pickup availability
Buy with the right details confirmed
Confirm the size, power, connections, and included or separately required parts described on this page.
Professional installation is recommended for this product.
- Authorized retailer New, authentic product from MCOR Automotive.
- Fast U.S. shipping Review shipping details
- Expert help since 2004 Ask MCOR before you order
- Clear return terms Review the return policy
The A800.1 Altitude amplifier adds dedicated subwoofer power with selectable signal inputs and ParaBASS adjustment. Its 800-watt rating is specified at 1.33 ohms, so match the subwoofer configuration to the documented load ratings.
At a Glance
- 400 W x 1 at 4 ohms; 600 W x 1 at 2 ohms; 800 W x 1 at 1.33 ohms
- Selectable high-level or low-level input mode
- GTO signal-sensing turn-on
- Valet Mode limits the available volume when activated
- Start-stop compatible; manufacturer states operation up to 17 V
Compatibility & Installation Requirements
Universal amplifier installation requires a compatible audio signal, suitable speakers, correctly sized fused power and ground wiring, and a secure ventilated mounting location. Wiring and vehicle-specific integration parts are selected separately. Match speaker impedance and output power before installation; this is not a vehicle-specific plug-and-play kit. Confirm the vehicle's low-voltage supply and signal levels; EV compatibility does not mean connection to a high-voltage traction battery. ACR-1 is optional and sold separately.
Included Equipment
- A800.1 amplifier
Technical Specifications
| Brand | AudioControl |
|---|---|
| Model | A800.1 |
| UPC | 850038647728 |
| Sold as | Each (one product) |
| Continuous RMS power at 14.4 V | 400 W x 1 at 4 ohms; 600 W x 1 at 2 ohms; 800 W x 1 at 1.33 ohms |
| Channels | 1 |
| Inputs | 2 |
| Maximum input voltage | 6 V low-level; 20 V high-level |
| Crossover | Low-pass 60–120 Hz; variable subsonic filter |
| Remote level control | Optional ACR-1, not included |
| Maximum stated supply compatibility | 17 V |
Manufacturer Resources & Warranty
One-year manufacturer warranty, subject to AudioControl eligibility and installation terms. Extended professional-installation coverage is not automatically included with a shipped product. View manufacturer warranty terms.
Help Choosing Your Setup
Tell MCOR Automotive your vehicle, factory or aftermarket radio, speakers and planned amplifier configuration. Contact us for help checking the signal path and installation requirements before you order.
